Mindray DC-80 User Manual

Image Optimization 5-53
5.10.4.3 4D Real-time Display
In 4D real-time display status, operations are similar to those in Static 3D. For the details, please
refer to the corresponding contents in Static 3D.
4D Real-time Editing
You can remove unnecessary information from the VR in real-time scanning by using a line tool.
1. Tap [Tool] to enter editing mode in 4D real-time review state.
2. Press <Set>to place the start position of the editing.
3. Roll the trackball to adjust the orientation, and then press <Set> to confirm the boundary.
4. Move the cursor to the area to be edited. Press <Set> to finish editing.
Tap [Undo] or [Undo All] to return to the previous step.
5.10.4.4 4D Image Saving
 In the 4D Review mode, press <Save> (with user-defined saving function) to save the current
image to the patient information management system in the set format.
 Save cine: in 4D viewing mode, press the user-defined save key to save CIN-format clip to the
hard drive.
5.10.4.5 3D/4D Fast Switching
During 4D viewing mode, press to switch to VR viewing status quickly, where you can
obtain the same image of a better quality.
During 3D viewing mode, press to switch to 4D image real-time status quickly, where you
can obtain the same image of dynamic mode.

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
