Mindray DC-80 User Manual

5-84 Image Optimization
7. Exit contrast imaging.
Press to exit the contrast imaging mode; or, press <B> button to return to B mode.
5.12.2 Left Ventricular Opacification
Basic Procedures for LVO:
1. Acquire ECG signal；
2. Press to open Probe/Exam Mode selecting dialogue box;
3. Select P4-2NE or SP5-1E probe and LVO exam mode;
4. Workflow of LVO is similar to abdomen contrast imaging. For details, please refer to ―5.12.1
Basic Procedures for Contrast Imaging‖.
5.12.3 Contrast Image Parameters
5.12.3.1 Parameter Area Display
When entering contrast imaging mode, the screen displays the contrast image, and if [Dual Live]
item on the touch screen is ―ON‖, both the contrast image (marked with ― ‖) and tissue image
(marked with ― ‖) are displayed (the two window position can be changed). Parameter area
displays as follows:
Type
Parameter
Description
Contrast
F
Contrast frequency.
D
Depth.
G
Gain.
FR
Frame rate.
DR
Dynamic Range.
Z
Magnification factor
iTouch
iTouch status
iClear
iClear status
Tissue
G
Gain
DR
Dynamic Range.
Z
Magnification factor

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
