Mindray DC-80 User Manual

10-4 Patient Data Management
 To exit Review:
 Click [Exit] on the Review screen
 Press <ESC>.
 Basic operations
Select an exam from the ―Exam History‖ drop-down list.
Double-click a thumbnail to view and analyze an image.
The function buttons are described as follows:
 Exam History:
You can select one certain exam from the exam directory to review the images.
 If entered from iStation, the screen displays the record(s) selected in the iStation.
 If entered from the imaging status, the Review screen displays the images of the
current exam, and the default selected image is the one displayed on the preview main
screen.
 Info
Click to enter the Patient Info screen, you can review or edit the currently-selected patient
information.
 Report
Click to review or edit the currently-selected patient report.
 Image operations
[Select All]: click to select all images in the thumbnail window.
[Deselect All]: after clicking the [Select All], the button changes into [Deselect All], you can
cancel all the selections by clicking [Deselect All].
[Send To]: click to send the selected image to other location, DICOM server, printer and
etc. Or, select the image and click the icon on the upper right of the image.
[Delete]: click to delete the selected image.
[Image Compare]: see Chapter 6.5 for details.
 Thumbnail Size
To change the thumbnail size.
 Other operations:

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
