Mindray DC-80 User Manual

2-4 System Overview
Probe
model
Probe Type
Intended Use
Region
Applied
LM14-6E
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric
Body surface
L16-4HE
Linear
Musculoskeletal, nerve, small parts, vascular,
pediatric, intra-operative
Body surface
P7-3E
Phased
Cardiac, abdomen, nerve, pediatric
Body surface
P10-4E
Phased
Cardiac, abdomen, nerve, pediatric
Body surface
P4-2NE
Phased
Cardiac, vascular, abdomen
Body surface
P7-3TE
Phased
Cardiac
Transesophagel
SP5-1E
Phased
Cardiac, vascular, abdomen
Body surface
V11-3E
Convex
Gynecology, obstetrics, urology
Transvaginal
V11-3BE
Convex
Gynecology, obstetrics, urology
Transvaginal
V11-3HE
Convex
Gynecology, obstetrics, urology
Transvaginal
C7-3E
Convex
Abdomen, gynecology, obstetrics, vascular
Body surface
C11-3E
Convex
Abdomen, vascular
Body surface
C5-1E
Convex
Abdomen, gynecology, obstetrics, vascular,
nerve
Body surface
SC5-1E
Convex
Obstetrics, gynecology, abdomen, vascular
Body surface
C6-2GE
Convex
Abdomen, gynecology, obstetrics
Body surface
D6-2NE
Volume
Obstetrics, gynecology, abdomen
Body surface
D7-2E
Convex (4D)
Obstetrics, gynecology, abdomen
Body surface
D8-2E
Convex (4D)
Obstetrics, gynecology, abdomen
Body surface
DE10-3E
Convex (4D)
Gynecology, obstetrics, urology
Transvaginal
DE11-3E
Convex (4D)
Gynecology, obstetrics, urology
Transvaginal
CW2s
Pencil probe
Cardiac
Body surface
CW5s
Pencil probe
Vascular
Body surface
CB10-4E
Bi-plane (convex
& convex)
Urology
Transrectal
Some of the probes have matched needle-guided brackets for biopsy, the available probes and the
corresponding needle-guided brackets are listed as follows:
Probe model
Needle-guided Bracket
Model
Biopsy
angle/depth
(±1°)
Applicable Biopsy Needle
V11-3E/
V11-3BE/
CB10-4E
NGB-004
metal/needle un-detachable
/
16G, 17G, 18G
L14-6NE/
L12-3E/
L14-6WE
NGB-007
plastic/needle detachable
metal/needle detachable
40°, 50°, 60°
Metal: 14G, 16G, 18G, 20G, 22G
Plastic: 13G, 15G, 16G, 18G, 20G

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
