Mindray DC-80 User Manual

2-12 System Overview
No.
Symbol
Function
<1>
Connects the control port of the video printer.
<2>
USB ports.
<3>
<4>
Network port.
<5>
Audio signal input port, left channel.
<6>
Audio signal input port, right channel.
<7>
Audio signal output port, left channel.
<8>
Audio signal output port, right channel.
<9>
Used for separate video input.
<10>
Used for separate video output.
<11>
Serial port, connects the serial port devices.
<12>
Used for DVI-D signal output.
<13>
HDMI
High definition multimedia interface.
<14>
VGA
VGA signal output.
<15>
Used for composite video input.
<16>
Used for composite video output.
<17>
/
3.3V power indicator.
<18>
/
5V power indicator.
<19>
/
12V power indicator.
NOTE:
1.
S-VIDEO port performs better in analog video print.
2.
When connecting an external video device (HDMI/VGA), please make sure the
display setting for resolution is 1920*1080, otherwise the image quality may be
degraded.

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
