Mindray DC-80 User Manual

4-2 Exam Preparation
4.1.1 New Patient Information
The Patient Info screen is shown as follows:
Place the cursor onto the targeted box. The field box is highlighted and a flashing cursor appears.
Information can be entered or selected from the options.
You can also change the cursor position by <Tab>, <Enter> or up/down controls.
Information includes:
1. General information
 Patient ID
Patient ID is generated automatically by the system after starting a new patient, and can be
modified manually. Once you enter the ID and confirm it, you are not allowed to change it.―\‖ is
not permitted.
The ID can be obtained by the bar code reader as well.
 Name
Enter patient name through the keyboard.
 Gender
Select Male, Female or Unknown for patient gender in the drop-down list.
 DOB (Date of birth):
You can either enter the birth date of a patient manually;
Or, click to select the date and click [OK] to finish.
 Age
 Auto generated age: once the DOB is obtained, the system can display an auto-
generated age in the field box; the unit can be ―Years‖, ―Months‖ or ―Days‖. If the age is
less than one year, the system will automatically calculate the age in months or days.
 Also, you can manually enter the age.
NOTE:
When you enter the date manually, please enter it in the format as that of the system.
2
1
4
3

Mindray DC-80 Specifications

General

Imaging Modes	B, M, Color Doppler, Power Doppler, Pulsed Wave Doppler, Continuous Wave Doppler, Tissue Doppler, 3D/4D Imaging
Probes	Convex, Linear, Phased Array, Volume
Advanced Features	Auto Optimization, Auto EF
Connectivity	DICOM 3.0, USB, HDMI, VGA, Ethernet
Transducer Ports	4
Applications	Abdominal, Cardiac, Obstetrics/Gynecology, Vascular, Small Parts, Musculoskeletal, Urology, Pediatrics, Neonatal
Transducer Types	Convex, Linear, Phased Array, Volume
Power Supply	100-240V AC, 50/60Hz
Operating Temperature	10°C to 40°C
Storage Temperature	-20°C to 60°C
Humidity	30% to 80%
