27
Basic Procedures for Static 3D Imaging
1.
Select the appropriate static 3D-compatible probe and connect it to the ultrasound
system. Make sure there is sufficient gel on the probe for scanning.
2.
Select the scanning probe and exam mode, and do parameter preset if necessary.
3.
Obtain a 2D image. Optimize the image as usual.
4.
Enter 3D/4D imaging preparation status:
z Press the user-defined key on the control panel; or,
z Click [3D/4D] in the soft menu; or,
z Move the cursor onto the image menu, navigate the cursor to [Other] item
and press
. Select [3D/4D] in the Other menu to enter the 3D/4D
imaging mode.
5.
Switch to static 3D mode by clicking [Static 3D], and define the ROI and curve
VOI. Press
to switch among the statuses of changing ROI and VOI.
6.
Select a parameter pack, and set parameters in the soft menu accordingly.
7.
Click [Start]; or, press on the control panel to begin the 3D image
acquisition.
The system enters 3D image viewing status when the acquisition is completed; or,
you can finish the acquisition ahead by clicking [Stop] in the soft menu (or press
or on the control panel).
In image viewing status, the system supports the following functions:
z Parameters adjustment in 3D image render.
z B-mode parameters adjustment.
z Set the display format.
z View the surface data.
z Define VOI position.
z Rotate 3D image.
z Image zooming.
z Image edit.
z 3D image parameters adjustment.
8.
Exit static 3D.
Press
to return to Static 3D acquisition preparation status; or,
Press
to exit Static 3D mode.
