Mindray M7Vet - Special Imaging Mode: Free Xros M

22
15 Special Imaging Mode: Free Xros M
 Assign a user-defined key for Free Xros M:
Enter “[Setup] (by pressing
)→ [System Preset] → [Key Config]” to set.
 Real-time Imaging
1. In real-time B mode or M mode, adjust the probe and image to obtain the desired
plane.
2. Click [Free Xros M] in the soft menu or menu to enter Free Xros M mode, or
press the user-defined key.
3. Adjusting the M-mark (single or multiple) line to obtain optimized images and
necessary information.
In Dual-split or Quad-split mode, it is the current activated window that enters the
Free Xros M Mode.
 Imaging in Freeze Mode
1. Free Xros M imaging of images in cine memory
z For B frozen images, press <M> or click [Free Xros M] in the soft menu, or
press the user-defined key directly.
z For B+M frozen images, click [Free Xros M] in the soft menu, or press the
user-defined key directly.
z For B+PW/ CW frozen images, enter single-B cine memory first and click
[Free Xros M] in the soft menu or press <M> on the control panel, or press
the user-defined key.）.
z In the dual-split or quad-split scanning, it is the current activated window that
enters the Free Xros M mode, and press
to switch between the
images in dual-split or quad-split B mode images.
2. Adjust the M-mark line (single or multiple) and image parameters to obtain
optimized images and necessary information.
