19 Image Display
Splitting Display
The system supports dual-split and quad-split display format. However, only one
window is active.
z Dual-split: press <Dual> key on the control panel to enter the dual-split mode,
and using <Dual> key to switch between the two images; press
to
exit.
z Quad-split: press <Quad> key on the control panel to enter the dual-split
mode, and using <Quad> key to switch between the two images; press
to exit.
Image Magnification
z Enter Zoom
In the real time scanning or freeze status, press
to enter the zoom
status.
z Zoom Adjustment
Rotate the multifunctional knob to change the magnification factor.
Rotate the multifunctional knob to the left to decrease the magnification factor;
rotate to the right to increase the magnification factor.
The magnification factor is displayed in the image parameter area and menu
area. For example,
indicates the current magnification factor is 1.3.
Roll the trackball to change the zoom position.
z Exit Zoom
Press
again or to exit the zoom status.
iZoom (Full-screen Zooming)
According to the region to be zoomed, the system supports two types of full-
screen zooming:
z The first type is to zoom in the standard area, including image area,
parameter area, image banner, thumbnail area and so on.
z The second type is to zoom in the image area in the full screen.
1.
Assign a user-defined key for iZoom:
Enter “[Setup] (by pressing
)→ [System Preset] → [Key Config]” to set.
2.
Open the image (or the under scanning image), press the user-defined iZoom key
once to zoom in image in the way of the first type, and then press the key again to
zoom in the image in the way of the second type.
3.
Press the user-defined key again to return to normal status.
