18 Special Imaging Mode: iScape
You can perform the iScape panoramic imaging feature on B real time images using
all linear and convex probes (including 4D probes).
To perform iScape imaging:
1.
Connect an appropriate iScape-compatible probe. Make sure that there is enough
coupling gel along the scan path. Set parameters if necessary.
2.
Enter iScape:
z Click [iScape] in the soft menu in B-mode; or,
z Press the user-defined key on the control panel; or,
z Move the cursor onto the image menu, navigate the cursor to [Other] item and
press
. Select [iScape] in the Other menu to enter the iScape imaging
mode.
3.
Optimize the B mode image:
In the acquisition preparation status, switch to [B] page tab to go for the B mode
image optimization. Do measurement or add comment/body mark to the image if
necessary.
4.
Image acquisition:
Click [iScape] page tab to enter the iScape acquisition preparation status. Click
[Start Capture] or press
on the control panel to begin the acquisition.
The system enters image viewing status when the acquisition is completed.
5.
Exit iScape:
z Press
to return to iScape preparation; or press button to
return to B mode.
z If it is in the capture status, click [Exit] in the menu; or, press the key.
