74
Service Manual Combics
Connection Function
1 OUT5_LOW
2 OUT5_HIGH
3 OUT4_LOW
4 OUT4_HIGH
5 OUT3_LOW
6 OUT3_HIGH
7 OUT2_LOW
8 OUT2_HIGH
9 OUT1_LOW
10 OUT1_HIGH
11 IN5_LOW
12 IN5_HIGH
13 IN4_LOW
14 IN4_HIGH
15 IN3_LOW
16 IN3_HIGH
17 IN2_LOW
18 IN2_HIGH
19 IN1_LOW
20 IN1_HIGH
Interface Description | Unicom PCBs
