3. Device description | 3.3 - Housing | 24
Connection Description
Analog weighing electronics Analog weighing platforms and analog load cells can be
connected (via a cable junction box).
3 digital inputs Contact inputs, for example, can be implemented. See
ChapterDigital inputs for an example.
3 digital outputs Current or voltage inputs, for example, can be imple
mented. See ChapterDigital outputs for an example.
RS-232 interface The following devices can be connected via the serial in
terface:
– Remote display
– Printer
RS-485 interface The following devices can be connected via the serial in
terface:
– ModBus RTU
– PC via SMA protocol
1 analog output The analog output can be used to control valves, for ex
ample.
Fieldbus interface:
– ProfiBus-DP
– DeviceNet
– ProfiNet I/O
– EtherNet/IP
The corresponding device can be included under a com
munication master (e.g. Siemens S7 ProfiBus) as a field
bus slave.
