3. Device description | 3.3 - Housing | 26
Pos. Connection Description
6 Pressure compensation element It provides pressure equalization in the device.
7 3 digital outputs Current or voltage inputs, for example, can be im
plemented. See ChapterDigital outputs for an ex
ample.
8 3 digital inputs Contact inputs, for example, can be implemented.
See ChapterDigital inputs for an example.
9 RS-485 interface The following devices can be connected via the seri
al interface:
– ModBus RTU
– PC via SMA protocol
10 RS-232 interface The following devices can be connected via the seri
al interface:
– Remote display
– Printer
