25
EXTERNAL POWER SUPPLIES (SOLD SEPARATELY)
The AC Adapter allows the camera to be powered from an electrical household outlet. The AC
Adapter is recommended when the camera is interfaced with a computer or during periods of heavy
use. AC Adapter model AC-1L is for use in North America, Japan, and Taiwan, and AC-11 is for use
in all other areas.
The External High-power Battery Pack Kit EBP-100 is a portable power source and significantly
extends the operating time of the camera. The kit contains a high-power lithium-ion battery, holder,
and charger. The battery, holder, and charger are also available separately.
Remove the DC terminal cover from the right (1).
The cover is attached to the body to prevent loss.
Insert the mini plug of the AC adapter or battery
pack into the DC terminal (2).
Insert the AC adapter plug into an electrical outlet.
Always turn off the camera and confirm the access lamp is not lit
before changing between power supplies.
1
2
