Minolta DYNAX 7 Repair Guide

(2181) 39
REPAIR GUIDE
■■
■■
■
Fig.1Fig.1
Fig.1Fig.1
Fig.1
■■
■■
■
Fig.2Fig.2
Fig.2Fig.2
Fig.2
Aperture Preset Check
Equipment Required
HIT Controller
ROM Pack for 2181
Contact Jig for 2181
Contact Jig Cable
I/F Box for HIT
HIT I/O Tester
Preset Signal Adapter
Check
1. Set up the equipment as in Fig. 1, and set camera to "M" mode and "Bulb".
2. Press Reset Button on HIT I/O Tester so that "00" appears in the display.
3. Set aperture to f/11, and release the shutter.
Check the reading in HIT I/O Tester is within the standard. (Reading appears while Shutter-release
Button is pressed all-the-way down.)
If the reading is out of standard, make Aperture Preset adjustment.
NOTE:These indications look similar
in HIT I/O Tester display
Figures in HIT I/O Tester is in hexadecimal notation.
-------- 6
-------- b
Adjustment
1. Set up the equipment as in Fig. 2.
2. Select "PRITRIGGER ADJ." from the main menu and press SELECT Button.
3. Press SELECT Button again.
4. Press Reset Button on HIT I/O Tester so that "00" appears in the display.
5. Press Shutter-release Button partway down. (S1 ON)
The shutter is automatically released twice. Confirm the average of readings at HIT I/O Tester.
6. Input the average to HIT Controller, then press SELECT Button.
First digit: Press Control Pad while pressing and holding Button-A.
Second digit: Press Control Pad while pressing and holding Button-B.
7. Repeat step-4 to -6. The adjustment is automatically done for each aperture settings; f/4.5,f/9.5,f/19.
8. Press Shutter-release Button partway down. "COMPLETE" appears when adjustment is complete.
9. Press SELECT Button to return to the main menu.
HIT I/O TesterHIT I/O Tester
HIT I/O TesterHIT I/O Tester
HIT I/O Tester
PRE/FLA: PRESET PRE/FLA: PRESET
PRE/FLA: PRESET PRE/FLA: PRESET
PRE/FLA: PRESET
Preset Signal AdapterPreset Signal Adapter
Preset Signal AdapterPreset Signal Adapter
Preset Signal Adapter
Contact Jig for 2181Contact Jig for 2181
Contact Jig for 2181Contact Jig for 2181
Contact Jig for 2181
CameraCamera
CameraCamera
Camera
Exposure mode: M Exposure mode: M
Exposure mode: M Exposure mode: M
Exposure mode: M
Focus mode: MF Focus mode: MF
Focus mode: MF Focus mode: MF
Focus mode: MF
I/F Box for HITI/F Box for HIT
I/F Box for HITI/F Box for HIT
I/F Box for HIT
ROM Pack for 2181ROM Pack for 2181
ROM Pack for 2181ROM Pack for 2181
ROM Pack for 2181
HIT ControllerHIT Controller
HIT ControllerHIT Controller
HIT Controller
Standard f/11: Ab - bb
HIT I/O TesterHIT I/O Tester
HIT I/O TesterHIT I/O Tester
HIT I/O Tester
PRE/FLA: PRESET PRE/FLA: PRESET
PRE/FLA: PRESET PRE/FLA: PRESET
PRE/FLA: PRESET
CameraCamera
CameraCamera
Camera
Exposure mode: M Exposure mode: M
Exposure mode: M Exposure mode: M
Exposure mode: M
Focus mode: MF Focus mode: MF
Focus mode: MF Focus mode: MF
Focus mode: MF
Preset Signal AdapterPreset Signal Adapter
Preset Signal AdapterPreset Signal Adapter
Preset Signal Adapter
Contact Jig CableContact Jig Cable
Contact Jig CableContact Jig Cable
Contact Jig Cable

Minolta DYNAX 7 Specifications

General

Camera Type	SLR
Film Format	35mm
Flash Sync Speed	1/200 sec
Sensor Type	N/A (Film Camera)
Sensor Size	N/A (Film Camera)
Effective Pixels	N/A (Film Camera)
Lens Mount	Minolta A mount
Shutter Speed	1/8000 to 30 sec, Bulb
ISO Range	ISO 6 to 6400
ISO Sensitivity	ISO 6 to 6400
Viewfinder	Pentaprism
Storage Media	N/A (Film Camera)
