44 (2181)
REPAIR GUIDE
■■
■■
■
Fig.1Fig.1
Fig.1Fig.1
Fig.1
■■
■■
■
Fig.2Fig.2
Fig.2Fig.2
Fig.2
■■
■■
■
Fig.3Fig.3
Fig.3Fig.3
Fig.3
■■
■■
■
Fig.4Fig.4
Fig.4Fig.4
Fig.4
(Pitch)(Pitch)
(Pitch)(Pitch)
(Pitch)
(Yaw)(Yaw)
(Yaw)(Yaw)
(Yaw)
②②
②②
② Pitch Yaw Adjustment
Turn a flood lamp toward camera during Pitch Yaw Adjustment.
How to Peform Adjustment
Pitch Adjustment
1. Attach AF-Y/P Adjuster to the camera, and set Pitch Adjusting Plate as in Fig. 1.
2. Select "PITCH, YAW ADJ." from the main menu and press SELECT Button.
3. Press and hold Shutter-release Button partway down after Naviagation Display goes out, so that lines
with two dents and a value appear in the display and remain for 5 sec.
4. Adjust the Pitch Adjusting Screw as in Fig.4 so that reading is within the standard. Then go on to Yaw
adjustment below.
Yaw Adjustment
5. Attach AF-Y/P Adjuster to the camera, and set Yaw Adjusting Plate as in Fig. 3.
6. Adjust the Yaw Adjusting Screw as in Fig.4 so that reading is within the standard.
7. Press SELECT Button while pressing and holding Shutter-release Button partway down (S1 ON) to
return to the previous menu.
Check
Perform "① AF Area Adjustment" and "② Pitch Yaw Adjustment" repeatedly until all readings meet the
respective standard.
Pitch Adjusting PlatePitch Adjusting Plate
Pitch Adjusting PlatePitch Adjusting Plate
Pitch Adjusting Plate
■■
■■
■
Insert the plate until it stops.Insert the plate until it stops.
Insert the plate until it stops.Insert the plate until it stops.
Insert the plate until it stops.
Yaw Adjusting PlateYaw Adjusting Plate
Yaw Adjusting PlateYaw Adjusting Plate
Yaw Adjusting Plate
■■
■■
■
Insert the plate until it stops.Insert the plate until it stops.
Insert the plate until it stops.Insert the plate until it stops.
Insert the plate until it stops.
Item Standard
Pitch 077 - 130
Yaw 073 - 137
Pitch Adjusting ScrewPitch Adjusting Screw
Pitch Adjusting ScrewPitch Adjusting Screw
Pitch Adjusting Screw
Yaw Adjusting ScrewYaw Adjusting Screw
Yaw Adjusting ScrewYaw Adjusting Screw
Yaw Adjusting Screw
To Next Page
