(2181) 51

REPAIR GUIDE

Memorize the number printed on the bar code put on the CCD ASSY, when CCD ASSY (2181-0271) or

MAIN BOARD ASSY (2181-0455) is replaced.

If CCD ASSY (2181-1001) is exchanged for new one, exchange the bar code on the BACK SUS PLATE

(2181-1001) for the bar code put on the new CCD ASSY.

Required equipment

PC with preinstalled the 2181 adjustment program

CF card for Adjustment

AC Adapter AC-11

USB-2 (USB cable)

* Use the AC adapter (AC-11) not batteries when adjusting.

Preparation of adjustment

Set camera to adjustment mode. Refer to Starting up the 2720 adjustment program. (P49)

Adjustment process

1. Click VSUB in adjustment menu.

CCD V-sub Adjustment windows is appeared.

2. Input memorized number on the CCD ASSY and click OK.

3. OK is displayed and adjustment is complete.

Adjustment of CCD Vsub voltage
