20
Mechanical Installation
5.0 Mechanical Installation
5.1 Installing the Enclosures
Install the FX-350 Series Fire Alarm Panel enclosure as shown below. Mount the enclosure
using the four mounting holes and the screws provided.
Figure 1 Wallbox Dimensions / Mounting the FX-350 – Surface
11"
14.5"
1.5"
14.5"
5.4"
4.5"
20"
Mounting
Hole
Mounting Hole
Mounting
Hole
Mounting Hole
