Appendix C: Specifications
16.2 FX-350 System Modules and Annunciators
Compliance System Model FX-350 SERIES, Fire Alarm Control Panel
System Type Local, Auxiliary (using PR-300), Remote Protected
Premise Station (using PR-300 or FX-350-60-DR or
FX-350-126-DR), Central Station Protected
Premises (using FX-350-60-DR or FX-350-126-DR).
Proprietary Protected Premise Unit, where PPU is
neither co-located with, nor integral with the
supervising station (NFPA 72).
Type of Service A, M, WF, SS
Type of Signalling Non-Coded
Applicable Standards NFPA 70 and 72, UL 864 R9, ULC S-524, ULC S-
527-11, CAN/ULC-S559-04
Table 10 FX-350 System Modules and Annunciators
FX-350 System Modules and Annunciators
OCAC-304 Output Class A Converter Module standby: 0 mA / alarm: 0 mA
RAM-208 Zone Remote Annunciator Standby 35mA / alarm 90mA
RAM-216 Zone Ancillary Annunciator Standby 35mA / alarm 140mA
RAM-300LCD LCD Remote Annunciator Standby 16mA / alarm 40mA
PR-300 Polarity Reversal and City Tie Module power limited / 24VDC unfiltered / 250mA max
/14Ohms trip
coil
Polarity Reversal power limited / 24VDC open / 12VDC at
3.5mA / 8.5mA max
(shorted)
Polarity Reversal Supv. Terminal 24VDC (normal) / -24VDC (supervisory) / 0V
(trouble)
Polarity Reversal Alarm Terminal 24VDC (normal) / -24VDC (alarm) / 0V
(trouble)
Current Consumption standby 50mA / alarm 300mA (city tie in use) /
alarm 70mA
(city tie not in use)
RTI Remote Trouble Indicator Standby 35mA / alarm 35mA
