Mircom FX-350 Series User Manual

36
Field Wiring
the main fire alarm board, from the top down. Refer to Figure 6 and Figure 7 for terminal
locations.
Figure 15 Dialer Wiring
Refer to Chapter 13.0 Dialer Operation on page 58 and Chapter 15.0 Appendix B:
Reporting on page 60 for more information regarding the built-in dialer.
TTRR
premise telephone
IF permitted
TTRR
LINE-1
LINE-2
1
23
4
8
5
76
Public switch
Telephone company
wiring
TIP
RING
TIP
RING
RJ31X
GREY
BROWN
RED
GREEN
COCO RESRES
Line 2 is Wired as shown for Line 1
FIRE ALARM MAIN BOARD
