47
Indicators, Controls and Operations
addressable device configured as General Alarm. The General Alarm condition remains active
until the panel is reset.
11.2.10System Reset Button
The System Reset button resets the panel and all circuits:
11.2.11AUTOMATIC ALARM SIGNAL CANCEL Button (Two Stage or PAS only)
If the panel is configured for two stage operation, activation of the AUTOMATIC ALARM
SIGNAL CANCEL button while the Auto General Alarm Timer is timing (e.g. there is an alarm
in the panel but it is still in the first stage) cancels the timer and turns the AUTOMATIC ALARM
SIGNAL CANCEL LED ON steady amber. If the panel is configured for Positive Alarm
Sequence (PAS), activation of the AUTOMATIC ALARM SIGNAL CANCEL button within 15
seconds of a PAS alarm will delay a common alarm activation for 60 seconds.
11.2.12Lamp Test Button
Pressing and holding the Lamp Test button causes all front panel indicators to illuminate and
sounds the buzzer steadily. Bi-coloured LEDs will illuminate twice to show both colors. If lamp
test is active for more than ten seconds, the Common Trouble LED activates.
11.3 Single Stage Operation
In a single stage system, all alarm inputs are treated in a similar manner. Alarm inputs include
any of the following: non-verified alarm, verified alarm, waterflow alarm, and general alarm
circuits. Any of these alarm inputs occurring when the panel is not already in alarm cause the
following:
• The buzzer sounds steadily
• If fire drill is active, it is cancelled
• The Common Alarm LED turns ON
• The Common Alarm relay activates if Aux disconnect is not active
• The Auto Signal Silence timer, if configured, starts. For Canadian installations, disable
Auto Signal Silence.
• The Signal Silence Inhibit timer, if configured, starts
• All non-disconnected indicating programmed to the input are activated provided that Aux
disconnect is not active
• Resets Aux Resettable Power Supply • Turns off all Indicating Circuits
• Turns OFF Signal Silence, Ack & GA LEDs • Turns off Fire Drill
• Stops and resets all Timers • Processes inputs as new events
• Aux Disconnect is not affected
• Reset cannot be activated until the
Signal Silence Inhibit timer has
expired
• Pressing Reset button after a PAS
Acknowledge will reset the system
and clear the alarm event.
Attention: After power-up, press the System Reset button to bring the system to
normal and restore the “system power up” trouble.
