45
Indicators, Controls and Operations
11.1.9 Signal Silence LED
The Signal Silence LED flashes
amber at the Trouble Flash rate
after indicating circuits are silenced
either by the Signal Silence button,
or by the Auto Signal Silence Timer.
It turns OFF after the signals are re-
sounded by a subsequent alarm.
For Canadian installations, disable Auto Signal Silence.
11.1.10Fire Drill LED
The Fire Drill LED turns ON steady amber while Fire Drill is active.
11.1.11ALM/SUP/TBL/BLDG AUDIBLE SIL LED (Buzzer Silence)
The ALM/SUP/TBL/BLDG AUDIBLE SIL LED flashes amber at the Trouble Flash rate when
the ALM/SUP/TBL/BLDG AUDIBLE SIL button is pressed. Any new alarm, supervisory or
trouble events will resound the buzzer and will cause the ALM/SUP/TBL/BLDG AUDIBLE SIL
LED to turn off.
11.1.12AUTOMATIC ALARM SIGNAL CANCEL LED (Acknowledge)
If the panel is configured as a two stage system, the AUTOMATIC ALARM SIGNAL CANCEL
LED turns ON steady amber after the Auto General Alarm Timer is cancelled by the activation
of the AUTOMATIC ALARM SIGNAL CANCEL or Signal Silence buttons. If the Auto General
Alarm Timer times out and puts the panel into General Alarm, the AUTOMATIC ALARM
SIGNAL CANCEL LED turns OFF. If the panel is configured as Positive Alarm Sequence
(PAS), the AUTOMATIC ALARM SIGNAL CANCEL LED flashes amber at the Fast Flash rate
while a timer counts down 15 seconds to common alarm.
11.1.13General Alarm LED
The red General Alarm LED illuminates steadily after the General Alarm button is pressed, a
general alarm initiating circuit is activated, or the Auto General Alarm timer times out. Once
the General Alarm LED turns on, it will stay active until the panel is reset.
11.1.14Lamp Test LED
The amber Lamp Test LED will illuminate steadily after the Lamp Test button is pressed and
while system is in Lamp Test mode.
11.1.15Battery/Charger Trouble LED
In a ULI application the amber Battery/Charger Trouble LED flashes at the Trouble Flash rate
when any Battery/Charger Trouble occurs.
In a ULC application the amber Battery/Charger Trouble LED illuminates steady when any
Battery/Charger Trouble occurs.
11.1.16LEDs 1 to 32 for FX-351 and FX-353 Series Only
Points labelled 1 to 32 are available for alarm, supervisory, and property and building safety
annunciation (bi-coloured red/amber LEDs) and trouble annunciation (amber LEDs).
11.1.17RAX-332 LEDs 33 to 64 for FX-351 and FX-353 Series Only
Points labelled 33 to 64 are available for alarm, supervisory, and property and building safety
annunciation (bi-coloured red/amber LEDs) and trouble annunciation (amber LEDs).
SYSTEM
RESET
FIRE
DRI LL
AUTOMATIC ALARM
SIGNAL CANCEL
GENERAL
ALARM
S IGNAL
ALM/SUP/TBL/
BLDG AUDIBLE SIL
LAMP
TE S T
BATTERY/CHARGER
SILENCE
TROUBLE
