Mitel IP 5330 User Manual

8
Mitel Networks
5330 IP Phone
USING YOUR DEFAULT PHONE WINDOW AND KEYS
The 5330 IP Phone default phone windows and keys are shown and described
below. The Phone window provides access to programmable keys and the main
phone interface.
Getting Started with Your Phone
When you receive your phone, you need to program features and applications.
An Applications key is programmed and appears on the upper left side of the
display (see figure below).
Press Applications to program your phone’s settings, call forwarding and so
forth. See Using Your Phone Applications.
5330 IP Phone Window
1) Softkeys
2) Programmable Keys
3) Navigation Page Keys
4) Status Line
5) Information Area
6) Footer.

Mitel IP 5330 Specifications

General

Protocols	MiNet and SIP
Headset Port	Dedicated headset port
Fixed Function Keys	Hold, Transfer, Conference, Volume, Mute
Audio	Full-duplex speakerphone
Network Ports	2 x 10/100 Mbps Ethernet ports
Power	Power over Ethernet (PoE)
Weight	2.2 lbs
Dimensions	8.5 x 7.5 x 6.5 inches (216 x 191 x 165 mm)
