3 ANALOG OUTPUT MODULE REPLACEMENT
3 - 48
3.7.3 I/O signal comparison to programmable controller CPU
Sequence program change is required as the I/O signals differ.
For details of the I/O signals and sequence program, refer to the Digital-Analog Converter Module
User's Manual.
A62DA-S1 Q64DAN
Device
No.
Signal name
Device
No.
Signal name
Device
No.
Signal name
Device
No.
Signal name
X0 Watchdog timer error Y0
Not used
X0 Module READY Y0 Not used
X1 D/A conversion READY Y1 X1
Not used
Y1
CH1 Output enable/
disable flag
X2
Not used
Y2 X2 Y2
CH2 Output enable/
disable flag
X3 Y3 X3 Y3
CH3 Output enable/
disable flag
X4 Y4 X4 Y4
CH4 Output enable/
disable flag
X5 Y5 X5 Y5
Not used
X6 Y6 X6 Y6
X7 Y7 X7 Y7
X8 Y8 X8
High resolution mode
status flag
Y8
X9 Y9 X9
Operating condition
setting completion flag
Y9
Operating condition
setting request
XA YA XA
Offset/gain setting mode
status flag
YA User range write request
XB YB XB
Channel change
completion flag
YB Channel change request
XC YC XC
Setting value change
completion flag
YC
Setting value change
request
XD YD XD
Synchronous output
mode flag
YD
Synchronous output
request
XE YE XE Not used YE Not used
XF YF XF Error flag YF Error clear request
X10 Y10
X11 Y11
X12 Y12
X13 Y13
X14 Y14
X15 Y15
X16 Y16
X17 Y17
X18 Y18
X19 Y19
X1A Y1A
X1B Y1B Output enable
X1C Y1C
Not used
X1D Y1D
X1E Y1E
X1F Y1F
