5 MULTIPLEXER REPLACEMENT
5 - 9
As regarding A60MXR non-isolated multiplexer module, consider replacement using multiple Q64AD-
GH.
5.3.1 Performance comparison
5.3 A60MXR
Item A60MXR
Analog input
Voltage -10 to 0 to +10VDC (Input resistance value: 1M)
Current
-20 to 0 to +20mADC
(Input resistance value: 250)
Analog output voltage -10 to 0 to +10VDC
I/O characteristics
Analog input range
Analog output voltage (V)
*1
Voltage (V) Current (mA)
0 to +10 0 to +20
0 to +10
0 to + 5 0 to +20
+ 1 to + 5 + 4 to +20
-10 to +10 -20 to +20
- 5 to + 5 -20 to +20
0 to +10 0 to +20
0 to + 5
0 to + 5 0 to +20
+ 1 to + 5 + 4 to +20 + 1 to + 5
-10 to +10 -20 to +20
-10 to +10
- 5 to + 5 -20 to +20
-10 to +10 -20 to +20
- 5 to + 5
- 5 to + 5 -20 to +20
Overall accuracy ±0.3% (Digital output value ±12)
Absolute
maximum input
Voltage ±15V
Current ±30mA
Analog input points 16 channels/module
Multiplexer element Mercury plunger relay
Isolation method
Between the input terminal and programmable controller: photocoupler isolation
Between channels: mercury plunger relay isolation
Between channels
dielectric withstand voltage
500VDC (accuracy guarantee 500VDC)
Occupied I/O points
16 points (treated as empty slots)
(0 point setting is possible by I/O assignment.)
Connected terminal 38-point terminal block
Applicable wire size
0.75 to 2mm
2
(Applicable tightening torque: 39 to 59N•cm)
Applicable solderless terminal V1.25-3, V1.25-YS3A, V2-S3, V2-YS3A
Internal current consumption
(5VDC)
0.5A
Weight 0.6kg
