4 TEMPERATURE INPUT MODULE REPLACEMENT
4 - 49
4.6.4 Buffer memory address comparison
Sequence program change is required as the assignment of buffer memory differs.
For details of the buffer memory and sequence program, refer to the RTD Input Module/Channel
Isolated RTD Input Module User's Manual.
A68RD3N Q68RD3-G
Address
(decimal)
Name Read/write
Address
(decimal)
Name Read/write
0 Conversion enable/disable specification
R/W
0 Conversion enable/disable setting
R/W
1 Averaging processing selection 1
CH1 Time/count/moving average/time
constant setting
2 CH1 Averaging time/count 2
CH2 Time/count/moving average/time
constant setting
3 CH2 Averaging time/count 3
CH3 Time/count/moving average/time
constant setting
4 CH3 Averaging time/count 4
CH4 Time/count/moving average/time
constant setting
5 CH4 Averaging time/count 5
CH5 Time/count/moving average/time
constant setting
6 CH5 Averaging time/count 6
CH6 Time/count/moving average/time
constant setting
7 CH6 Averaging time/count 7
CH7 Time/count/moving average/time
constant setting
8 CH7 Averaging time/count 8
CH8 Time/count/moving average/time
constant setting
9 CH8 Averaging time/count 9 System area (Not used) -
10 CH1 Detected temperature value (16bit)
R
10 Conversion completion flag
R
11 CH2 Detected temperature value (16bit) 11 CH1 Measured temperature value
12 CH3 Detected temperature value (16bit) 12 CH2 Measured temperature value
13 CH4 Detected temperature value (16bit) 13 CH3 Measured temperature value
14 CH5 Detected temperature value (16bit) 14 CH4 Measured temperature value
15 CH6 Detected temperature value (16bit) 15 CH5 Measured temperature value
16 CH7 Detected temperature value (16bit) 16 CH6 Measured temperature value
17 CH8 Detected temperature value (16bit) 17 CH7 Measured temperature value
18 CH1 Detected temperature value (L)
(32bit) (H)
18 CH8 Measured temperature value
19 19 Error code
20 CH2 Detected temperature value (L)
(32bit) (H)
20 Setting range 1 (Input type CH1-4)
21 21 Setting range 2 (Input type CH5-8)
22 CH3 Detected temperature value (L)
(32bit) (H)
22 Setting range 3 (Offset/gain setting)
23 23 System area (Not used) -
24 CH4 Detected temperature value (L)
(32bit) (H)
24 Averaging processing selection (CH1-CH4)
R/W
25 25 Averaging processing selection (CH5-CH8)
26 CH5 Detected temperature value (L)
(32bit) (H)
26
Offset/gain setting mode (Offset
specification)
27 27 Offset/gain setting mode (Gain specification)
28 CH6 Detected temperature value (L)
(32bit) (H)
28 CH1 Offset temperature setting value
29 29 CH1 Gain temperature setting value
30 CH7 Detected temperature value (L)
(32bit) (H)
R
30 CH2 Offset temperature setting value
31 31 CH2 Gain temperature setting value
32 CH8 Detected temperature value (L)
(32bit) (H)
32 CH3 Offset temperature setting value
33 33 CH3 Gain temperature setting value
34 Write data error code R/W 34 CH4 Offset temperature setting value
35 Conversion completion flag R 35 CH4 Gain temperature setting value
36 Specification of platinum RTD type R/W 36 CH5 Offset temperature setting value
37 CH5 Gain temperature setting value
38 CH6 Offset temperature setting value
39 CH6 Gain temperature setting value
