Mitsubishi Electric MELSEC-A/QnA Series - Buffer Memory Address Comparison

2 ANALOG INPUT MODULE REPLACEMENT
2 - 25
2.4.4 Buffer memory address comparison
Sequence program change is required as the assignment of buffer memory differs.
For details of the buffer memory or sequence program, refer to the Channel Isolated Analog-Digital
Converter Module, Channel Isolated Analog-Digital Converter Module (With Signal Conditioning
Function) User's Manual.
A68AD Q68AD-G
Address
(Dec.)
Name Read/write
Address
(Dec.)
Name Read/write
0 Number of channels
R/W
0 A/D conversion enable/disable
R/W
1 Averaging processing specification 1
CH1 Average time/Average number of times/
Moving average/Time constant settings
2 CH1 Averaging time, count 2
CH2 Average time/Average number of times/
Moving average/Time constant settings
3 CH2 Averaging time, count 3
CH3 Average time/Average number of times/
Moving average/Time constant settings
4 CH3 Averaging time, count 4
CH4 Average time/Average number of times/
Moving average/Time constant settings
5 CH4 Averaging time, count 5
CH5 Average time/Average number of times/
Moving average/Time constant settings
6 CH5 Averaging time, count 6
CH6 Average time/Average number of times/
Moving average/Time constant settings
7 CH6 Averaging time, count 7
CH7 Average time/Average number of times/
Moving average/Time constant settings
8 CH7 Averaging time, count 8
CH8 Average time/Average number of times/
Moving average/Time constant settings
9 CH8 Averaging time, count 9 System area (Not used) -
10 CH1 Digital output value
R
10 A/D conversion completed flag
R
11 CH2 Digital output value 11 CH1 Digital output value
12 CH3 Digital output value 12 CH2 Digital output value
13 CH4 Digital output value 13 CH3 Digital output value
14 CH5 Digital output value 14 CH4 Digital output value
15 CH6 Digital output value 15 CH5 Digital output value
16 CH7 Digital output value 16 CH6 Digital output value
17 CH8 Digital output value 17 CH7 Digital output value
18
System area (Not used) -
18 CH8 Digital output value
19 19 Error code
20 20 Setting range (CH1 to CH4)
21 21 Setting range (CH5 to CH8)
22 22 Offset/gain setting mode Offset specification
R/W
23 23 Offset/gain setting mode Gain specification
24 24
Averaging process specification (CH1 to
CH4)
25 25
Averaging process specification (CH5 to
CH8)
26 26
System area (Not used) -
27 27
28 28
29 29
30 30 CH1 Maximum value
R
31 31 CH1 Minimum value
32 32 CH2 Maximum value
33 33 CH2 Minimum value
34 Write data error code R/W 34 CH3 Maximum value
to
44 CH8 Maximum value
45 CH8 Minimum value
