Mitsubishi Electric MELSEC-A/QnA Series User Manual

4 TEMPERATURE INPUT MODULE REPLACEMENT
4 - 30
Q64RD
Address
(decimal)
Name Read/write
48 Warning output flag
R
49 Disconnection detection flag
50 CH1 Scaling value
51 CH2 Scaling value
52 CH3 Scaling value
53 CH4 Scaling value
54 CH1 Measured temperature value (L)
(32bit) (H)
55
56 CH2 Measured temperature value (L)
(32bit) (H)
57
58 CH3 Measured temperature value (L)
59 (32bit) (H)
60 CH4 Measured temperature value (L)
61 (32bit) (H)
62 CH1 Scaling range lower limit value (L)
(H)
R/W
63
64 CH1 Scaling range upper limit value (L)
(H)
65
66 CH2 Scaling range lower limit value (L)
(H)
67
68 CH2 Scaling range upper limit value (L)
(H)
69
70 CH3 Scaling range lower limit value (L)
(H)
71
72 CH3 Scaling range upper limit value (L)
(H)
73
74 CH4 Scaling range lower limit value (L)
(H)
75
76 CH4 Scaling range upper limit value (L)
(H)
77
78 CH1 Scaling width lower limit value
79 CH1 Scaling width upper limit value
80 CH2 Scaling width lower limit value
81 CH2 Scaling width upper limit value
82 CH3 Scaling width lower limit value
83 CH3 Scaling width upper limit value
84 CH4 Scaling width lower limit value
85 CH4 Scaling width upper limit value
86 CH1 Warning output lower (L)
87 lower limit value (H)
88 CH1 Warning output lower (L)
89 upper limit value (H)
90 CH1 Warning output upper (L)
91 lower limit value (H)
92 CH1 Warning output upper (L)
93 upper limit value (H)
to
116 CH4 Warning output upper (L)
R/W
117 upper limit value (H)
118 CH1 Offset temperature setting value (L)
119 (H)
120 CH1 Gain temperature setting value (L)
121 (H)
