Mitsubishi Electric MELSEC-A/QnA Series - Page 211

4 TEMPERATURE INPUT MODULE REPLACEMENT
4 - 68
Q64RD-G
Address
(decimal)
Name Read/write
39
System area (Not used) -
40
41
42
43
44
45
46
47 Warning output enable/disable setting R/W
48 Warning output flag
R
49 Disconnection detection flag
50 to 53 CH1 to CH4 Scaling value
54 CH1 Measured temperature (L)
value (32bit) (H)
55
to
60 CH4 Measured temperature (L)
value (32bit) (H)
R
61
62 CH1 Scaling range lower limit value (L)
(H)
R/W
63
64 CH1 Scaling range upper limit value (L)
(H)
65
to
76 CH4 Scaling range upper limit (L)
value (H)
R/W
77
78 CH1 Scaling width lower limit value
79 CH1 Scaling width upper limit value
to
85 CH4 Scaling width upper limit value
R/W
86 CH1 Warning output lower lower (L)
limit value (H)
87
88 CH1 Warning output lower upper (L)
limit value (H)
89
90 CH1 Warning output upper lower (L)
limit value (H)
91
92 CH1 Warning output upper upper (L)
limit value (H)
93
to
116 CH4 Warning output upper upper (L)
limit value (H)
R/W
117
118 CH1 Offset temperature setting value (L)
(H)
119
120 CH1 Gain temperature setting value (L)
(H)
121
to
132 CH4 Gain temperature setting value (L)
(H) R/W
133
134 Extended averaging processing selection
135 to
147
System area (Not used) -
148
Conversion setting for disconnection
detection
R/W
149 System area (Not used) -
150 CH1 Conversion setting value for (L)
disconnection detection (H)
R/W
151
