7 POSITIONING MODULE REPLACEMENT
7 - 5
Manual pulse generator
function
1 generator/axis 1 generator/module
• On QD75PN/
QD75DN, the
manual pulse
generator cannot
be used by each
axis
independent.
When connecting
the manual pulse
generator for
each axis is
required, use
one axis module.
• The manual
pulse generator
itself can use the
same one.
• The operation for
inputting one
pulse differs.
Set the
parameter so
that movement
amount may be
same.
Starting time 20ms
1.5 to 2.0ms
(when other axes are starting:
1.5 to 2.0ms + 0.1ms to 0.5ms)
The starting time
becomes fast.
Check the
processing timing.
Acceleration
/deceleration
processing
Automatic
trapezoidal
acceleration/
deceleration
S-pattern
acceleration/
deceleration
Acceleration
/deceleration
time
No. of
patterns
Acceleration time and deceleration time
can be set independently.
(4 patterns each)
Acceleration time and deceleration time
can be set independently.
(4 patterns each)
Setting
range
Changeover between 1 to 65535ms/1
to 8388608ms possible
1 to 8388608ms
Sudden stop
deceleration
Changeover between 1 to 65535ms/1
to 8388608ms possible
1 to 8388608ms
Compensation
Electronic gears, backlash
compensation, near pass
*3
Electronic gears, backlash
compensation, near pass
*3
Refer to *3.
Error display 17-segment LED Error LED ×
For details of
diagnostic, use GX
Developer.
History data storage (Start,
error, warning)
Provided (4 types, 16 items/module)
Provided
(3 types, 16 items/module)
The start history
during error is
integrated into the
start history.
Data storage destination
Flash ROM
(battery-less backup)
Flash ROM
(battery-less backup)
: Compatible, : Partial change required, ×: Incompatible
Model
Item
AD75P1-S3 AD75P2-S3 AD75P3-S3
QD75P1N
QD75D1N
QD75P2N
QD75D2N
QD75P4N
QD75D4N
Compat-
ibility
Precautions for
replacement
