Mitsubishi Electric MELSEC-A/QnA Series - Page 29

2 ANALOG INPUT MODULE REPLACEMENT
2 - 10
46
System area (Not used) -
46
System area (Not used) -
47 47
48
INPUT channel digital output value R
48
to to
63 63
64
System area (Not used) -
64
to to
157 157
158 158
Mode switching setting R/W
159 159
160 160
System area (Not used) -
to to
201 201
202 202 CH1 Industrial shipment settings offset value
R/W
203 203 CH1 Industrial shipment settings gain value
204 204 CH2 Industrial shipment settings offset value
205 205 CH2 Industrial shipment settings gain value
206 206 CH3 Industrial shipment settings offset value
207 207 CH3 Industrial shipment settings gain value
208 208 CH4 Industrial shipment settings offset value
209 209 CH4 Industrial shipment settings gain value
210 210 CH5 Industrial shipment settings offset value
211 211 CH5 Industrial shipment settings gain value
212 212 CH6 Industrial shipment settings offset value
213 213 CH6 Industrial shipment settings gain value
214 214 CH7 Industrial shipment settings offset value
215 215 CH7 Industrial shipment settings gain value
216 216 CH8 Industrial shipment settings offset value
217 217 CH8 Industrial shipment settings gain value
218 218 CH1 User range settings offset value
219 219 CH1 User range settings gain value
220 220 CH2 User range settings offset value
221 221 CH2 User range settings gain value
222 222 CH3 User range settings offset value
223 223 CH3 User range settings gain value
224 224 CH4 User range settings offset value
225 225 CH4 User range settings gain value
226 226 CH5 User range settings offset value
227 227 CH5 User range settings gain value
228 228 CH6 User range settings offset value
229 229 CH6 User range settings gain value
230 230 CH7 User range settings offset value
231 231 CH7 User range settings gain value
232 232 CH8 User range settings offset value
233 233 CH8 User range settings gain value
234
to
255
256
MX. CH. channel digital output value R
to
383
A616AD Q68ADV/I
Address
(Dec.)
Name Read/write
Address
(Dec.)
Name Read/write
