2 ANALOG INPUT MODULE REPLACEMENT
2 - 42
Q68AD-G
Address
(Dec.)
Name Read/write
46 System area (Not used) -
47
Input signal error detection extended/input
signal error detection setting R/W
48 Warning output setting
49 Input signal error detection flag
R
50 Warning output flag (Process alarm)
51 Warning output flag (Rate alarm)
52 System area (Not used)
-
53 Scaling enable/disable setting
R/W
54 CH1 Scaling value
R
to
61 CH8 Scaling value
62 CH1 Scaling lower limit value
R/W
63 CH1 Scaling upper limit value
to
76 CH8 Scaling lower limit value
77 CH8 Scaling upper limit value
to
86 CH1 Process alarm lower lower limit value
87 CH1 Process alarm lower upper limit value
88 CH1 Process alarm upper lower limit value
89 CH1 Process alarm upper upper limit value
to
114 CH8 Process alarm lower lower limit value
115 CH8 Process alarm lower upper limit value
116 CH8 Process alarm upper lower limit value
117 CH8 Process alarm upper upper limit value
118 CH1 Rate alarm warning detection period
to
125 CH8 Rate alarm warning detection period
126 CH1 Rate alarm upper limit value
127 CH1 Rate alarm lower limit value
to
140 CH8 Rate alarm upper limit value
141 CH8 Rate alarm lower limit value
142
CH1 Input signal error detection setting
value/CH1 Input signal error detection lower
limit setting value
to
150
CH1 Input signal error detection upper limit
setting value
to
158
Mode switching setting R/W
159
to
200 Save data classification setting R/W
201 System area (Not used) -
202 CH1 Factory default offset value
R/W
203 CH1 Factory default gain value
to
232 CH8 Factory default offset value
233 CH8 Factory default gain value
