2 ANALOG INPUT MODULE REPLACEMENT
2 - 53
Item A68ADN
Maximum conversion speed 20ms/channel
Response time -
Absolute maximum input
Voltage: ±15V
Current: ±30mA
Analog input points 8 channels/module
Maximum number of writes for
E
2
PROM
-
Isolation method
Between the input terminal and programmable controller power supply: photocoupler isolation
Between channels: non-isolated
Dielectric withstand voltage Between the I/O terminal and programmable controller power supply: 500VAC, for 1 minute
Insulation resistance Between the I/O terminal and programmable controller power supply: 500VDC, 5M or more
Occupied I/O points
32 points
(I/O assignment: special 32 points)
Connected terminal 38-point terminal block
Applicable wire size
0.75 to 2mm
2
(Applicable tightening torque: 39 to 59N•cm)
Applicable solderless terminal V1.25-3, V1.25-YS3A, V2-S3, V2-YS3A
Internal current consumption
(5VDC)
0.4A
Weight 0.51kg
