Mitsubishi Electric MELSEC-Q00U(J)CPU

488
(9) Scan time measurement
When the scan time is measured (Page 181, Section 3.13.3), the processing time listed in the following table is
required.
*1 The number of the branch instructions is a total of the following instructions, which are executed during the scan time
measurement.
• Pointer branch instruction: CJ, SCJ, JMP
• Subroutine program call instruction: CALL(P), FCALL(P), ECALL(P), EFCALL(P), XCALL(P), RET
(10)Monitor condition setting
When the monitor condition is set (Page 146, Section 3.11.1), the processing time listed in the following table is
required.
(11)Time taken to collect module errors
When using the module error collection, the scan time increases by the time found by the following calculation
formula. Each N1 and N2 in the calculation formula indicates the following.
 Calculation formula
Collection time = N1 + N2 × (Number of module errors collected in one scan)
CPU module Processing time
Q00UJCPU
180.3 + 5.9 × number of branch instructions µs
*1
Q00UCPU, Q01UCPU
179.5 + 5.8 × number of branch instructions µs
*1
Q02UCPU
40.0 + 3.0 × number of branch instructions µs
*1
Q03UD(E)CPU, Q04UD(E)HCPU, Q06UD(E)HCPU, Q10UD(E)HCPU,
Q13UD(E)HCPU, Q20UD(E)HCPU, Q26UD(E)HCPU, Q50UDEHCPU,
Q100UDEHCPU
40.0 + 1.5 × number of branch instructions µs
*1
Q03UDVCPU, Q04UDVCPU, Q04UDPVCPU, Q06UDVCPU, Q06UDPVCPU,
Q13UDVCPU, Q13UDPVCPU, Q26UDVCPU, Q26UDPVCPU
30.0 + 0.40 × number of branch instructions µs
*1
CPU module
Processing time
Specified step
matches the execution
condition
Specified device
matches the execution
condition (Device D
matches the condition)
Q02UCPU 30µs 40µs
Q03UD(E)CPU, Q03UDVCPU, Q04UD(E)HCPU, Q04UDVCPU,
Q04UDPVCPU, Q06UD(E)HCPU, Q06UDVCPU, Q06UDPVCPU,
Q10UD(E)HCPU, Q13UD(E)HCPU, Q13UDVCPU, Q13UDPVCPU,
Q20UD(E)HCPU, Q26UD(E)HCPU, Q26UDVCPU, Q26UDPVCPU
10µs 30µs
CPU module
Main base unit Extension base unit
N1 N2 N1 N2
Q00UJCPU 175µs --- 190µs ---
Q00UCPU, Q01UCPU 145µs 120µs 190µs 140µs
Q02UCPU 145µs 90µs 185µs 105µs
Q03UD(E)CPU, Q04UD(E)HCPU, Q06UD(E)HCPU,
Q10UD(E)HCPU, Q13UD(E)HCPU, Q20UD(E)HCPU,
Q26UD(E)HCPU, Q50UDEHCPU, Q100UDEHCPU
15µs 70µs 15µs 100µs
