Mitsubishi Electric MELSEC-Q00U(J)CPU

489
APPENDICES
A
Appendix 3 CPU Module Processing Time Appendix 3.3 Factors that increase the scan time
(12)Batch transfer of data to the program memory
When data in the program cache memory is batch-transferred to the program memory, the processing time listed
in the following table is required.
*1
*1 The time in the table is for the case where the service processing count is set to one.
(13) Diagnostics of the redundant power supply system
When the "Diagnose Redundant Power Supply System" is selected on the PLC RAS tab of the PLC parameter
dialog box, the processing time listed in the following table is required.
*1 A power supply module failure indicates any of the following.
• The redundant power supply module has failed.
• Power for the redundant power supply module is turned off.
• The redundant power supply module is not mounted.
Q03UDVCPU, Q04UDVCPU, Q04UDPVCPU, Q06UDVCPU,
Q06UDPVCPU, Q13UDVCPU, Q13UDPVCPU, Q26UDVCPU,
Q26UDPVCPU
6µs 45µs 6µs 70µs
CPU module
Processing time
Scan time = 2ms Scan time = 20ms
Q00UJCPU, Q00UCPU, Q01UCPU 2.35ms 5.10ms
Q02UCPU 2.35ms 4.50ms
Q03UDCPU 1.10ms 3.65ms
Q04UDHCPU, Q06UDHCPU, Q10UDHCPU, Q13UDHCPU,
Q20UDHCPU, Q26UDHCPU
1.05ms 3.65ms
Q03UDECPU, Q04UDEHCPU, Q06UDEHCPU, Q10UDEHCPU,
Q13UDEHCPU, Q20UDEHCPU, Q26UDEHCPU,
Q50UDEHCPU, Q100UDEHCPU
1.40ms 4.00ms
Q03UDVCPU, Q04UDVCPU, Q04UDPVCPU, Q06UDVCPU,
Q06UDPVCPU, Q13UDVCPU, Q13UDPVCPU, Q26UDVCPU,
Q26UDPVCPU
0.60ms 0.60ms
CPU module
Processing time
With a power supply
module failure
*1
Without a power supply
module failure
*1
Q00UCPU
125µ
s 165µs
Q01UCPU
125µ
s 135µs
Q02UCPU
90µ
s 90µs
Q03UD(E)CPU, Q03UDVCPU, Q04UD(E)HCPU, Q04UDVCPU,
Q04UDPVCPU, Q06UD(E)HCPU, Q06UDVCPU, Q06UDPVCPU,
Q10UD(E)HCPU, Q13UD(E)HCPU, Q13UDVCPU,
Q13UDPVCPU, Q20UD(E)HCPU, Q26UD(E)HCPU,
Q26UDVCPU, Q26UDPVCPU, Q50UDEHCPU, Q100UDEHCPU
43µ
s 52µs
CPU module
Main base unit Extension base unit
N1 N2 N1 N2
