4G1 ENGINE (E-W) -
Specifications
11A-1-2a
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
Item Standard Limit
Crankshaft and cylinder block
Crankshaft end play mm 0.05- 0.18 0.25
Crankshaft journal diameter mm 48.0 -
Crankshaft pin diameter mm 42.0 -
Crankshaft journal oil clearance mm 0.02- 0.04 0.1
Cylinder block gasket surface flatness mm 0.05 or less -
Cylinder block gasket surface grinding limit (including grinding of
cylinder head gasket surface) mm
- 0.2
Cylinder block overall height mm 256 -
Cylinder block cylindricity mm 0.01 -
Cylinder block I. D. mm
4G13 71.0 -
4G15 75.5 -
4G18 76.0 -
Piston-to-cylinder clearance mm 0.02- 0.04 -
PWEE9520-A
E
Dec. 1998Mitsubishi Motors Corporation Added
