Mitsubishi 4G1 series Workshop Manual

4G1 ENGINE (E-W) -
Oil Pump and Oil Pan
11A-10-1
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
10. OIL PUMP AND OIL PAN
REMOVAL AND INSTALLATION
11
1
12
14
13
16
15
10
9
8
6
5
7
2
3
10 Nm
13 Nm
44 Nm
18 Nm
7Nm
4
39 Nm
23 Nm
Apply engine oil to all
moving parts before
installation.
Removal steps
"
E
A
1. Oil filter
2. Drain plug
"
D
A
3. Gasket
4. Transmission stay
(Rear wheel drive)
A
A
""
C
A
5. Oil pan
6. Oil screen
7. Gasket
8. Relief valve
9. Relief valve spring
10. Relief plunger
"
B
A
11. Front oil seal
"
A
A
12. Front case
13. O-ring
14. Oil pump cover
15. Oil pump outer rotor
16. Oil pump inner rotor
PWEE9520-A
E
Dec. 1998Mitsubishi Motors Corporation Revised
