4G1 ENGINE (E-W) -
Timing Belt
11A-4-1
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
4. TIMING BELT
REMOVAL AND INSTALLATION <SOHC>
11 Nm
1
10
12
35 Nm
4
3
7
2
5
23 Nm
88 Nm
11
9
8
9Nm
13
6
Removal steps
1. Timing belt upper cover
2. Timing belt lower cover
A
A
""
C
A
3. Timing belt
"
B
A
4. Tensioner spring
"
B
A
5. Timing belt tensioner
6. Crankshaft angle sensor
<Rear wheel drive>
7. Crankshaft sprocket
8. Spacer <Rear wheel drive>
9. Sensing blade <Rear wheel drive>
A
B
""
A
A
10. Camshaft sprocket bolt
11. Camshaft sprocket
12. Engine support bracket
13. Timing belt rear cover
PWEE9520-A
E
Dec. 1998Mitsubishi Motors Corporation RevisedPWEE9520-A
E
Dec. 1998Mitsubishi Motors Corporation Revised
