Mitsubishi 4G1 series Workshop Manual

4G1 ENGINE (E-W) -
Fuel and Emission Control Systems
11A-5-2a
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <SOHC-REAR WHEEL DRIVE>
11 Nm
18 Nm
21 Nm
9Nm
1
2
3
11
6
4
5
9
10
8
7
13
12
9Nm
Removal steps
1. Throttle body assembly
2. Gasket
3. Fuel return pipe
"
B
A
4. Fuel pressure regulator
5. O-ring
6. Insulator
7. Insulator
"
A
A
8. Injector
9. O-ring
10. Grommet
11. Delivery pipe
12. EGR valve
13. Gasket
PWEE9520-A
E
Dec. 1998Mitsubishi Motors Corporation Added
