Mitsubishi 4G1 series

4G1 ENGINE (E-W) -
Water Pump and Water Hose
11A-6-2
PWEE9520
E
Nov. 1995Mitsubishi Motors Corporation
REMOVAL AND INSTALLATION <SOHC-MPI>
2
13 Nm
12
10
9
11
12 Nm
11 Nm
4
29 Nm
3
8
7
6
22 Nm
5
23 Nm
1
Removal steps
1. Water hose
2. Water hose
"
E
A
3. Water temperature sensor
"
D
A
4. Water temperature gauge unit
5. Water inlet fitting
"
C
A
6. Thermostat
7. Thermostat case
8. Gasket
"
B
A
9. Water inlet pipe
"
B
A
10. O-ring
"
B
A
11. O-ring
"
A
A
12. Water pump
