Mitsubishi 4G9 - Intake Manifold (GDI) Removal and Installation (from 2001 Model for Carisma, Space Star and Galant)

4G9 ENGINE (E–W) – Intake Manifold (GDI)
11A-6a-1a
PWEE9502-D
E
Jun. 1998Mitsubishi Motors Corporation Added
REMOVAL AND INSTALLATION
<From 2001 model for CARISMA, SPACE STAR and GALANT>
11 Nm
19 Nm
4
5
1
3
11 Nm
19 Nm
2
Removal steps
1. Vacuum pipe and hose
2. Purge hose
3. Solenoid valve
4. Vacuum pipe
5. Intake manifold
PWEE9502-L
E
Apr. 2003Mitsubishi Motors Corporation Revised
