Mitsubishi 4G9 - Exhaust Manifold (GDI) Removal and Installation (for Pajero Io)

4G9 ENGINE (E-W) -
Exhaust Manifold (GDI)
11A-6b-2
REMOVAL AND INSTALLATION <For PAJERO io>
17 Nm
13 Nm
1
3
5
2
4
29 Nm
18 Nm
98 Nm
29 Nm
Removal steps
1. Exhaust manifold cover
2. Engine hanger
"
B
A 3. Exhaust manifold bracket
4. Exhaust manifold
5. Exhaust manifold gasket
PWEE9502-E
E
Dec. 1998Mitsubishi Motors Corporation Revised
