Mitsubishi FREQROL-SF - NO. Common Signal, description, waveform

219 pages

To Next Page

To Previous Page

No.

Common

Signal,

description, waveform

CH36 AGA

Power voltage peak current

Example of waveform) Motor stop state(M05)

55-I

CH37 AGA

AD converter input

(speed feedback and voltage command detection)

Example of waveform)

READY ON,

Motorstop

state

(MO51

o- 1 1

0-m

11v

CH38 AGA

+lO

V reference voltage

9.7

10.5 v

CH39

AGA

Regeneration converter current detection

Example of waveform)

Motor deceleration

O-

3. 5

Continued

the next

-160-
