1.3
Adjusting speed and load meter
(1)
Adjusting speed meter
The speed meter can be adjusted when a speed meter
(DC ammeter full-scale: 1
mA)
is connected between the
ammeter terminals
SMl
and OM (see Appendixes 1-4 and
l-5).
Turn on the dip switch
SW5-4
on the SF-CA card (see
Reference
1.1.1
(3)) so that the speed meter reads the full
Section 3.1.1 (3)) so that the speed meter reads the full
scale (the maximum speed which is set by the parameter
#17
TSP becomes the full-scale).
(2) Adjusting load meter
The load meter can be adjusted when a load meter (DC am-
meter full-scale:
1
mA)
is connected between the ammeter
terminals
LMl
and OM (see Appendixes l-4 and l-5).
Turn on the dip switch
SW5-4
on the SF-CA card and adjust
the VR5 so that the load meter reads the full scale.
(Note
1)
After the speed meter or load meter is adjusted,
return the dip switch
SW5-4
back to the OFF posi-
tion.
(Note 2) Since other volume have been set at
factory,
do not adjust them.
1.4
Setting and adjusting spindle orientation control circuit
See Section 3,
"Spindle orientation control circuit".
-214-
