5 - 29 5 - 29
MELSEC-Q
5 UTILITY PACKAGE (GX Configurator-AD)
5.8.2 Paste an FB to a Sequence Program
[Purpose of operation]
Paste an FB in order to use it with a sequence program.
[Operation procedure]
Switch the <<Project>> tab into the <<FB>> tab on GX Developer, and drag &
drop the FB to be used onto the sequence program.
A
fter pasting
Before pasting
