Mitsubishi GX Configurator-AD User Manual

A - 11 A - 11
About the Generic Terms and Abbreviations
Unless otherwise specified, this manual uses the following general terms and
abbreviations.
Abbreviation/general terms Description of the abbreviation/general terms
A/D converter module Generic term for Q64AD-GH and Q62AD-DGH
DOS/V personal computer IBM PC/AT
®
or compatible computer with DOS/V.
GX Developer
Generic product name of the product types SWnD5C-GPPW-E, SWnD5C-GPPW-EA,
SWnD5C-GPPW-EV and SWnD5C-GPPW-EVA.
"n" in the model name is 4 or greater.
GX Configurator-AD
Generic term for analog-digital converter module setting and monitor tool GX
Configurator-AD (SW2D5C-QADU-E)
QCPU (Q mode)
Generic term for Q00JCPU, Q00CPU, Q01CPU, Q02CPU, Q02HCPU, Q06HCPU,
Q12HCPU, Q25HCPU, Q12PHCPU, Q25PHCPU
QnPHCPU Generic term for Q12PHCPU and Q25PHCPU.
Personal computer Generic term for DOS/V personal computer
Industrial shipment setting
Generic term for analog input ranges 0 to 10V, 0 to 5V, 1 to 5V, -10 to 10V, 0 to 20mA
and 4 to 20mA
FB Abbreviation of function block.
