3 - 38 3 - 38
MELSEC-Q
3 SPECIFICATIONS
3.4.5 Averaging process specification (buffer memory address 9: Un\G9)
(1) When selecting sampling processing or averaging processing, write the setting to
buffer memory address 9 (Un\G9).
(2) When you selected averaging processing, select the average time, average count,
move average or primary delay filter.
(3) To make the setting valid, the operating condition setting request (Y9) must be
turned ON/OFF. (Refer to Section 3.3.2.)
(4) By default, sampling processing is set for all channels.
b15 b12 b11 b8 b7 b4 b3 b0to to to to
CH4 CH3 CH2 CH1
For Q62AD-DGH, information of b8 to b15 is fixed at 0.
Processing method Setting value
Sampling processing 0
H
Time averaging 1
H
Count averaging 2
H
Move averaging 3
H
Primary delay filter 4
H
Example
When setting channel 1 for count averaging, channel 2 for time averaging, channel 3 for
primary delay filter, and channel 4 for sampling processing, store 412H
(1042) into the
buffer memory address 9 (Un\G9).
b15
CH4 CH3 CH2 CH1
240
412H (1042)
0000010000010010
b14b13b12b11b10b9b8b7b6b5b4b3b2b1b0
1
POINT
For the channel where the value outside the above setting range has been written,
operation is performed by sampling processing.
To Next Page
