7 - 18 7 - 18
MELSEC-Q
7 ONLINE MODULE CHANGE
(d) Monitor the digital output values (buffer memory addresses 11 to 14, 54 to
62, Un\G11 to 14, Un\G54 to 62) to check whether proper conversion has
been made or not.
(5) Resumption of control
(a) After choosing [Diagnosis] - [Online module change] on GX Developer to
redisplay the "Online module change" screen, click the [Execution] button to
resume control. The FROM/TO instruction for the module resumes.
(b) The "Online module change completed" screen appears.
To Next Page
