1 - 3 1 - 3
MELSEC-Q
1 OVERVIEW
(12) Offset/gain setting
GX Configurator-AD, dedicated instruction (G. OFFGAN) or mode switching
setting allows a shift to the offset/gain setting mode easily.
(13) Easy settings using the utility package
A utility package is sold separately (GX Configurator-AD).
The utility package is not a required item, however, it is useful for on-screen
setting of the intelligent function module parameters (initial setting/auto refresh
setting). In addition, FB
1
can be generated automatically from the intelligent
function module parameters that have been set up and used in a sequence
program.
1: FB is the function for making a circuit block used in a sequence program
repeatedly a part (FB) to use it in the sequence program.
This function can improve the efficiency of program development and
minimize program bugs to improve program qualities.
For the details of FB, refer to "GX Developer Version 8 Operating Manual
(Function Block)."
