Mitsubishi GX Configurator-AD User Manual

APP -9 APP -9
MELSEC-Q
A
PPENDI
X
Control data of Q64AD-GH (2/2)
Device Item Set data Setting range Set by
(S) + 12
(S) + 13
CH3 Industrial shipment settings offset value (L)
(H)
——System
(S) + 14
(S) + 15
CH3 Industrial shipment settings gain value (L)
(H)
——System
(S) + 16
(S) + 17
CH4 Industrial shipment settings offset value (L)
(H)
——System
(S) + 18
(S) + 19
CH4 Industrial shipment settings gain value (L)
(H)
——System
(S) + 20
(S) + 21
CH1 user range settings offset value (L)
(H)
——System
(S) + 22
(S) + 23
CH1 user range settings gain value (L)
(H)
——System
(S) + 24
(S) + 25
CH2 user range settings offset value (L)
(H)
——System
(S) + 26
(S) + 27
CH2 user range settings gain value (L)
(H)
——System
(S) + 28
(S) + 29
CH3 user range settings offset value (L)
(H)
——System
(S) + 30
(S) + 31
CH3 user range settings gain value (L)
(H)
——System
(S) + 32
(S) + 33
CH4 user range settings offset value (L)
(H)
——System
(S) + 34
(S) + 35
CH4 user range settings gain value (L)
(H)
——System
Control data of Q62AD-DGH (1/2)
Device Item Set data Setting range Set by
(S) System area — — —
(S) + 1 Completion status
Stores the status when the
instruction is complete.
0 : Normal completion
Other than 0: Abnormal completion
—System
(S) + 2
(S) + 3
System area — — —
(S) + 4
(S) + 5
CH1 Industrial shipment settings offset value (L)
(H)
——System
(S) + 6
(S) + 7
CH1 Industrial shipment settings gain value (L)
(H)
——System
(S) + 8
(S) + 9
CH2 Industrial shipment settings offset value (L)
(H)
——System
(S) + 10
(S) + 11
CH2 Industrial shipment settings gain value (L)
(H)
——System
(S) + 12
to
(S) + 19
System area — — —
